ISO/IEC 10918-1 : 1993(E)
TISO1000-93/d036
Generate_size_table
K = 0
I = 1
J = 1
No
Yes
HUFFSIZE(K) = I
K = K + 1
J = J + 1
J > BITS(I)
?
I = I + 1
J = 1
No
I > 16
?
Yes
HUFFSIZE(K) = 0
LASTK = K
Done
Figure C.1 ­ Generation of table of Huffman code sizes
Figure C.1 [D36], = 16 cm = 625 %
CCITT Rec. T.81 (1992 E)
51
