ISO/IEC 10918-1 : 1993(E)

TISO1480-93/d086

DECODE

I = 1

CODE = NEXTBIT

I = I + 1
CODE = (SLL CODE 1) + NEXTBIT

CODE > MAXCODE(I)

?

Yes

No

J = VALPTR(I)
J = J + CODE MINCODE(I)
VALUE = HUFFVAL(J)

Return VALUE

Figure F.16 Procedure for DECODE

Figure F.16 [D86] = 14 cm = 547 %

CCITT Rec. T.81 (1992 E)

109
